General Specifications

Warm up time

None required, 30 minute temperature stabilization recommended for best performance from cold power up

Resolution

To 1 ppm, user adjustable

Power requirements

100 to 240 V ac (-15%, +10%), 50-60 Hz, 70 VA max consumption

Operating temperature range

10 to 40 °C

Weight

16.6 kg (36.5 lb)

Dimensions

19 cm H x 35 cm W x 45 cm D (7.5 in. x 13.8 in. x 17.7 in.)

Remote communication interfaces

RS232 (COM1, COM2), IEEE-488.2, USB (front panel, firmware load only)

Operating medium

Any clean, dry, non-corrosive gas

Pressure connections

TEST (+), TEST (-):

1/8 in. NPT F

SUPPLY:

1/8 in. NPT F

EXHAUST:

3/8 in. NPT F

ATM:

10-32 UNF

PPC4E measurement uncertainty (includes precision and one year stability)1,2

PPC4EX 14M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 140

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.1
Minimum AutoRanged span [kPa]2: 140

PPC4E 14M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 1400
Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 1
Minimum AutoRanged span [kPa]2: 1400

PPC4EX 7M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 70

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.05
Minimum AutoRanged span [kPa]2: 70

PPC4E 7M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 700

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.5
Minimum AutoRanged span [kPa]2: 700

PPC4EX 1.4M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 14

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.014
Minimum AutoRanged span [kPa]2: 70

PPC4E 1.4M

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: 140

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.1
Minimum AutoRanged span [kPa]2: 140

PPC4EX 100K

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: ± 1

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.014
Minimum AutoRanged span [kPa]2:70

PPC4E 100K

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: ± 10

Absolute uncertainty1,4
% of AutoRanged span: 0.02
Constant [kPa]: 0.014
Minimum AutoRanged span [kPa]2: 70

PPC4E 15K

Gauge uncertainty1,3
% of AutoRanged span: 0.02
Minimum AutoRanged span [kPa]2: ± 1.5

On-board barometer

Warm up time

None required

Range

70 to 110 kPa (10 to 16 psi)

Resolution

0.001 % of span

Precision
Predicted stability

0.1 % of span
0.05 kPa/yr (0.008 psi/yr)

Pressure control specifications

Control precision

PPC4E:
±0.0006% of controller span

PPC4EX:
±0.0006% of controller span (AutoRanged span >10% of controller span)
±0.00006% of controller span (AutoRanged span ≤10% of controller span)

Lowest controllable pressure
(gauge mode)

Zero set by automated venting. Lowest point above or below zero limited only by RPT resolution and control precision.

Lowest controllable pressure
(absolute, negative gauge modes)

1 kPa absolute (0.15 psia) or gauge equivalent, for all models except PPC4E 7M and PPC4E 14M

3.5 kPa(0.5 psia) for PPC4E 7M

7 kPa(1 psia) for PPC4E 14M

Ultimate pressure
(absolute, negative gauge)
Depending on vacuum pump and connections

200 to 700 Pa absolute(2 to 7 mbar, 0.03 to 0.1 psia) or gauge equivalent

Typical pressure setting ready time
(0.005% hold limit, 50 cc test volume)

15 to 30 s

Slew time
(ATM to FS with 50 cc test volume)

30 s

Typical test volume

0 to 1000 cc for Controller Range of 1.4 MPa
[300 psi] or less
0 to 500 cc for Controller Range greater than 1.4 MPa [300 psi]

Default dynamic control hold limit

± 0.01 % of current range

型號

描述

6241-15K

PPC4E Gas Pressure Controller Kit with PPC4E 15K, ± 1.5 to ± 15 kPa (± 0.2 to ± 2.2 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6241-100K

PPC4E Gas Pressure Controller Kit with PPC4E 100K, ± 10 to ± 100 kPa (± 1.5 to ± 15 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6241-1.4M

PPC4E Gas Pressure Controller Kit with PPC4E 1.4M, 140 to 1,400 kpa (20 to 200 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6241-7M

PPC4E Gas Pressure Controller Kit with PPC4E 7M, 700 to 7,000 kPa (100 to 1,000 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6242-100K

PPC4E Gas Pressure Controller Kit with PPC4EX 100K, ± 1 to ± 100 kPa (± 0.15 to ± 15 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6242-1.4M

PPC4E Gas Pressure Controller Kit with PPC4EX 1.4M, 14 to 1,400 kpa (2 to 200 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6242-7M

PPC4E Gas Pressure Controller Kit with PPC4EX 7M, 70 to 7,000 kPa (10 to 1,000 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

6242-14M

PPC4E Gas Pressure Controller Kit with PPC4EX 14M, 140 to 14,000 kPa (20 to 2,000 psi)

Includes:

·         PPC4E pressure controller/calibrator with power line cords and operating manual

·         SPLT self-purging liquid trap with connector to PPC4E

·         Mountable test stand for device under test with interconnect and quick connect fitting with adapters

配件

描述

Case

加固且可重復使用的模制裝運外殼（部件號 3338097）

機架安裝套件

標準 19in 機架安裝工具機架

PK-PPC-BG-DVU

BG15K Q-RPT 用雙倍容積單元（部件號 3070389）

真空參考套件，，220V

用于 PPC EXHAUST 端口的真空泵套件包括連接器（部件號 3584486）

COMPASS for Pressure

自動執行測試、數據采集、報告與設備資產管理的軟件

RS232

9 針線，，2m，，用于 PPC4E COM1（部件號 2758335）
